SMV1247-011LF
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 9.5 |
| Maximum Reverse Voltage: | 15 V |
| Minimum Diode Capacitance: | 6.5@0.3V pF |
| Minimum Quality Factor: | 1500(Typ) |
| Tuning Ratio Test Condition: | 0.3/4.7 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
更新于 2025-11-06SVC230-TB-E
电气特性 Features
| Configuration: | Dual Common Cathode |
| Applications Type: | Tuner |
| Minimum Tuning Ratio: | 1.65 |
| Maximum Reverse Voltage: | 16 V |
| Minimum Diode Capacitance: | 44@2V pF |
| Minimum Quality Factor: | 100 |
| Tuning Ratio Test Condition: | 2/8 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
1SV329(TH3,F,T)
电气特性 Features
| Configuration: | Single |
| Applications Frequency Range: | UHF |
| Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 2.7 |
| Maximum Reverse Voltage: | 10 V |
| Minimum Diode Capacitance: | 5.7@1V pF |
| Tuning Ratio Test Condition: | 1/4 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
SMV1263-079LF
电气特性 Features
| Configuration: | Single |
| Applications Frequency Range: | VHF|UHF |
| Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 2.3 |
| Maximum Reverse Voltage: | 20 V |
| Minimum Diode Capacitance: | 6.2@0.5V pF |
| Tuning Ratio Test Condition: | 0.5/2.5 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
FSD273TA
电气特性 Features
| Configuration: | Dual Common Cathode |
| Applications Type: | VCXO|TCXO |
| Minimum Tuning Ratio: | 2 |
| Maximum Reverse Voltage: | 12 V |
| Minimum Diode Capacitance: | 45@0.5V pF |
| Minimum Quality Factor: | 250 |
| Tuning Ratio Test Condition: | 0.5/2.5 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
ZC834BTA
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCXO|TCXO |
| Minimum Tuning Ratio: | 5 |
| Maximum Reverse Voltage: | 25 V |
| Minimum Diode Capacitance: | 44.65@2V pF |
| Minimum Quality Factor: | 200 |
| Tuning Ratio Test Condition: | 2/20 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BB208-03,115
电气特性 Features
| Configuration: | Single |
| Applications Type: | VCO|VCXO|TCXO |
| Minimum Tuning Ratio: | 3.7 |
| Maximum Reverse Voltage: | 10 V |
| Minimum Diode Capacitance: | 19.9@1V pF |
| Tuning Ratio Test Condition: | 1/7.5 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BB565-02V H7902
电气特性 Features
| Configuration: | Single |
| Applications Frequency Range: | UHF |
| Type: | Tuner |
| Minimum Tuning Ratio: | 9 |
| Maximum Reverse Voltage: | 30 V |
| Minimum Diode Capacitance: | 18.5@1V pF |
| Tuning Ratio Test Condition: | 1/28 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
SMV1255-004LF
电气特性 Features
| Configuration: | Dual Common Cathode |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 11 |
| Maximum Reverse Voltage: | 15 V |
| Minimum Diode Capacitance: | 58@0.3V pF |
| Minimum Quality Factor: | 350(Typ) |
| Tuning Ratio Test Condition: | 0.3/4.7 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BBY55-02V H6327
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 2 |
| Maximum Reverse Voltage: | 16 V |
| Minimum Diode Capacitance: | 17.5@1V pF |
| Tuning Ratio Test Condition: | 2/10 V |
| Mounting: | Surface Mount |
SMV1408-001LF
电气特性 Features
| Configuration: | Single |
| Applications Frequency Range: | UHF |
| Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 4.1 |
| Maximum Reverse Voltage: | 30 V |
| Minimum Diode Capacitance: | 1.75@4V pF |
| Minimum Quality Factor: | 2900(Typ) |
| Tuning Ratio Test Condition: | 0/30 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BBY5303WE6327HTSA1
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 1.8 |
| Maximum Reverse Voltage: | 6 V |
| Minimum Diode Capacitance: | 4.8@1V pF |
| Tuning Ratio Test Condition: | 1/3 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
1SV282(TPH2,F)
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner |
| Minimum Tuning Ratio: | 12 |
| Maximum Reverse Voltage: | 34 V |
| Minimum Diode Capacitance: | 33@2V pF |
| Tuning Ratio Test Condition: | 2/25 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
BBY5302WE6327
电气特性 Features
| Configuration: | Single |
| Applications Type: | Tuner|VCO |
| Minimum Tuning Ratio: | 1.8 |
| Maximum Reverse Voltage: | 6 V |
| Minimum Diode Capacitance: | 4.8@1V pF |
| Tuning Ratio Test Condition: | 1/3 V |
| Mounting: | Surface Mount |
BB175X
电气特性 Features
| Configuration: | Single |
| Applications Frequency Range: | VHF |
| Type: | VCO |
| Minimum Tuning Ratio: | 20.6 |
| Maximum Reverse Voltage: | 32 V |
| Minimum Diode Capacitance: | 52@1V pF |
| Tuning Ratio Test Condition: | 1|28 V |
| Mounting: | Surface Mount |
| Operating Temperature: | -55 to 125 ℃ |
| Rad Hard: | No |
