IKD03N60RFATMA1
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 5 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Surface Mount |
| Operating Temperature: | -40 to 175 ℃ |
| Rad Hard: | No |
更新于 2025-11-06FGH60N60SMD_F085
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 120 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Operating Temperature: | -55 to 175 ℃ |
| Rad Hard: | No |
SKW20N60HS
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 36 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
STGF7NB60SL
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 15 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
IHW25N120R2FKSA1
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 1200 V |
| Maximum Continuous Collector Current: | 50 A |
| Maximum Gate Emitter Voltage: | ±25 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
IRG4BC40W-STRRP
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 40 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
SGF23N60UFTU
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 23 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
IGW25N120H3
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 1200 V |
| Maximum Continuous Collector Current: | 50 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
STGD3NB60SDT4
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 6 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
IRG7PH46UDPBF
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 1200 V |
| Maximum Continuous Collector Current: | 108 A |
| Maximum Gate Emitter Voltage: | ±30 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
NGTB40N65FL2WG
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 650 V |
| Maximum Continuous Collector Current: | 80 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Operating Temperature: | -55 to 175 ℃ |
| Rad Hard: | No |
IRGB4045D
电气特性 Features
- 超高速(8-30kHz)IGBT模块
- Vces: 600V
- Ic@100℃: 6.0A
- Vce(ON)@25℃(typ): 1.70V
IGP20N65H5XKSA1
电气特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 650 V |
| Maximum Continuous Collector Current: | 20 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Operating Temperature: | -40 to 175 ℃ |
| Rad Hard: | No |
IRG4BC15UD-L
电气特性 Features
- 超高速(8-30kHz)IGBT模块
- Vces: 600V
- Ic@100℃: 7.8A
- Vce(ON)@25℃(typ): 2.02V
IRGC4615B
电气特性 Features
- 超高速(8-30kHz)IGBT模块
- Vces: 600V
- Vce(ON)@25℃(typ): 1.55V
